Product Description

The ABB ACH180-04S-05A6-4 is an AC variable frequency drive ideal for HVAC applications. It is designed to handle a three-phase input voltage between three hundred eighty to four hundred eighty VAC. This drive supports a constant torque rating of two horsepower and a variable torque rating of three horsepower. It includes built-in operator controls and features an open-type enclosure.

Input Voltage: 380-480 VAC, 3-Phase
Constant Torque Rating: 2 HP (3.5 A)
Variable Torque Rating: 3 HP (4.8-5.3 A)

Product Highlights

The ABB ACH180 series offers reliable control for various HVAC systems, enhancing performance and efficiency. The drive's DIN rail mount design provides ease of installation in control panels and cabinets.

Product Information

Standard Information

Manufacturer: ABB
Product Series: ACH180

Technical Specifications

MPN: ACH180-04S-05A6-4
Input Phase: 3-Phase
Output Phase: 3-Phase
Nominal Input Voltage: 380 VAC, 415 VAC, 480 VAC
HP (Variable Torque Rating): 3 HP
Amps (Variable Torque Rating): 4.8 A
Amps (Constant Torque Rating): 3.5 A
AC Voltage: 380-480 VAC
Operator Controls: Built In
IP Rating: IP20
Mounting: DIN Rail
HP (Constant Torque Rating): 2 HP
Height: 7.48 inches
Width: 2.76 inches
Depth: 5.63 inches
Frequency: 63 Hz
Frame Size: R1
Net Weight: 3.865 lbs
Gross Weight: 3.865 lbs

Brand	ABB
MPN	ACH180-04S-05A6-4

ABB ACH180-04S-05A6-4 VFD 3-Phase 2/3 HP 380-480V DIN Rail IP20
