3 factory sealed boxes, 1 opened for photos.

Slimline Power System

48V DC Outside Plant and Customer Premise Solution. The Slimline Power System provides advanced controller features in a compact, cost-efficient footprint. The SPS platform is based around a 1RU shelf configuration with an array of combinations of rectifier shelves and distribution options to address 500W to 19200W applications. The Pulsar Edge controller has Ethernet connectivity to

facilitate remote network management to monitor and control rectifiers, batteries, and distribution. The SPS is a full featured and reliable DC power solution where system height and depth are restricted and large system performance is critical to success.

The Slimline Power System power shelf provides advanced controller features in a compact , cost-efficient footprint . The SPS

shelf is 1.75” high, 10.3” deep and mounts in 19-inch or 23-inch wide frames, with three power slots for rectifiers and distribution. The Pulsar Edge controller has Ethernet connectivity to facilitate remote network management to monitor and control rectifiers, batteries, and distribution. SPS is a reliable DC power solution where system height and depth are restricted.

Features

• SPS rectifiers produce 42Vdc to 58Vdc

output; up to 1600W high line, 1200W low

line

• Universal AC input: 90-290VAC

• AC input options: IEC-320 C13 or C19 style

cords and universal rear AC screw

terminal strip

• Temperature hardened harsh

environments. (-40°C to +75°C)

• Compact 1U (1.75”) 19” mount solutions

(23” adapters available)

• Adjustable mounting ears for either flush

front or 5- inch set back position

• Up to 4 rectifier shelves may be connected

together for larger power requirements

• Plug-N-Play SPS841A controller with Web

based interface available with or without

display. All controllers available with craft

port and remote LAN access.

• Integrated distribution options include

one or two 30A battery breakers, up to 10

GMT load fuses and Low Voltage Battery

Disconnect voltage and temperature

monitoring.

SPS features the Pulsar Edge controller delivering

large system intelligence in a small system form

factor. Ethernet connectivity with SNMP facilitates

remote network management.

Benefits

Reliability

• Simplified deployment

• Proven field performance

• Hardened for extreme environments

Intelligence

• Industry leading controller features

• Ethernet interface for remote access

• Centralized network management

Investment Protection

• Engineered to reduce installation time

• Versatile configurations

• Efficient operation

On Time Delivery

• Standard building blocks

• 4 - 6 week availability

• 24/7 technical support

• Customer premise power for converged

networks

• Large plant features in a small plant package

• 4800 Watt/90 Amps single shelf capacity in 1RU

• Expandable to 19200 Watts/ 360 Amps in 4800

Watt/90 Amp 1RU increments

• 10.3 inches (264mm) depth is ideal where space

is restricted.

• Over 95% Efficiency

• Flexible distribution options in 1RU increments

The SPS TE rectifiers are single phase, hot-pluggable, fan cooled rectifiers that provide highly reliable DC

power. As cost-effective rectifiers that occupy just 1RU, its shallow depth is an ideal power solution for

space critical applications. The constant output power characteristics as well as the extended

temperature range, universal AC input voltage range and compact size are key attributes that make this

rectifier the right choice for your power needs.

These rectifiers are applicable for indoor and outdoor environments especially where equipment depth

and height are restricted. The SPS TE rectifiers communicate digitally to the Pulsar Edge controller

family over a RS485 bus to add extensive monitoring and alarm management facilities. Its flexible and

sophisticated feature set makes this front-end supply an excellent choice for power in a variety of

application spaces.

Applications

• Telecommunications networks

• Digital subscriber line (DSL)

• Indoor/outdoor wireless

• Routers/switches

• Fiber in the loop

• Transmission

• Data networks

• PBX

Key Features

• Extended temperature range

• Redundant fan cooling

• Front panel LED indicators

• 1U height, minimized depth

• Universal AC input

• Analog load sharing

• Hot pluggable

• RoHS complian

Brand	GE
Model	J2007003 L004X
MPN	150039543
Country of Origin	Mexico

GE/ABB SPS-48V Slimline Power Shelf J2007003L004X, Lineage Power, NEW IN BOX
