Smart Technologies Smart Board MX265-V2 65" Interactive Display 4K SBID-MX265-V2

New - full accessories!

Has to ship Freight on a pallet - contact us for a quote

Model: SBID-MX265-V2 Specifications
Description	65" Interactive Display with iQ and SMARTBOARD Learning Suite
ENERGY STAR certified	As an ENERGY STAR certified signage display, the SMARTBOARD MX065-V2 interactive display meets strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and Department of Energy.
Dimensions and weights
Weight	102 lb. (46.1 kg)
Active touch area	57 3/8" × 32 3/4" (145.7 cm × 83.3 cm)
Active image area	56 1/4" × 31 5/8" (142.9 cm × 80.4 cm)
Shipping dimensions (including pallet)	66 3/8" W × 45 3/4" H × 10 1/4" D (168.5 cm× 116.2 cm × 26 cm)
Shipping weight	137 lb. (62 kg)
Hardware
Interaction
Touch technology	HyPr Touch with Advanced IR
Multitouch capabilities	Up to 20 simultaneous touch, writing, or erase points1 2
Object Awareness	Behavior adjusts automatically to the tool or object you’re using, whether it’s a pen, finger or palm.
Positioning accuracy	<2 mm
Display
Type	LED backlit LCD (A grade)
Aspect ratio	16:9
Resolution	4K UHD (3840 × 2160)
Horizontal frequency	31 Hz–140 kHz
Vertical frequency	59 Hz–70 Hz
Brightness (maximum)	≥400 cd/m²
Refresh frequency	60 Hz
Pixel clock (maximum)	590 MHz
Pixel dimensions	0.37 mm
Viewing angle	178°
Response time (typical)	8 ms
Ambient light sensor	Yes
Audio	15 W integrated speakers (×2)
Wireless	IEEE 802.11a/b/g/n/ac with 2 × 2 MIMO (both 2.4 and 5 GHz bands)
Included cables and accessories	Country-specific power cable 16' 5" (5 m) USB cable Wall mount bracket kit Pen (×2) Antenna (×2) IR remote control (with two AAA batteries)
iQ experience
Supported languages	Danish Dutch English Finnish French German Italian Korean Norwegian Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Ukrainian Vietnamese
Mounting holes	For a standard VESA 600 mm × 400 mm mounting plate with M8 screws
Mounting bracket depth	Minimum clearance depth of 1 1/4" (3 cm) for all components on the back of the interactive display for airflow
Software
Included software	iQ Android-based embedded computing One-year subscription to SMARTBOARD Learning Suite (including SMARTBOARD Notebook software) SMARTBOARD Notebook basic version SMARTBOARD Ink and SMARTBOARD Product Drivers
Other software (sold separately)
SMARTBOARD Remote Management	Cloud-based device management software for remotely maintaining, supporting, controlling, and securing the display and your other devices. Comes installed on the display and can be used as a 30-day trial before activation. See SMARTBOARD Remote Management for more information.
Connectors
Side connector panel	1 Accessory slot (for 60W OPS devices) 1 HDMI 1.4 out with HDCP support3 1 USB 2.0 Type-A (for service use only) 1 USB 3.0 Type-A (for currently selected input source) HDMI 1 1 HDMI in with HDCP 2.2 support 1 USB 3.0 Type-B (for touch) HDMI 2 1 HDMI in with HDCP 2.2 support 1 USB 3.0 Type-B (for touch)
Front connector panel	1 USB 2.0 Type-A (for the display) 1 USB 2.0 Type-A (for currently selected input source) HDMI 3 1 HDMI in with HDCP 2.2 support 1 USB 2.0 Type-B (for touch)
Bottom connector panel	1 RS-232 2 RJ45 1 S/PDIF out (fixed) 1 Stereo 3.5 mm out (variable) VGA 1 1 Stereo 3.5 mm in (for VGA in) 1 VGA in 1 USB 3.0 Type-B (for touch)
Installation requirements
Room computers and guest laptops
Interactive display	See the SMARTBOARD MX (V2) series interactive displays installation and maintenance guide (smarttech.com/kb/171555).
General requirements	See SMARTBOARD Notebook software release notes
4K UHD	Video card that can support 3840 × 2160 resolution at 60 Hz. See Minimum requirements for Ultra High Definition or 4K on your interactive flat panel.
Cable requirements
HDMI	Maximum length: 23' (7 m) Notes: Use only certified HDMI cables that have been tested to support the performance standard you require. The performance of cables longer than 23' (7 m) is highly dependent on the cable’s quality.
USB 2.0	USB 2.0 certified Hi-Speed (480 Mbps) support Maximum length: 16' (5 m)
USB 3.0	USB 3.0 certified SuperSpeed (5 Gbps) support Maximum length: 9' (3 m)
Storage and operating requirements
Power requirements	100V to 240V AC, 50 Hz to 60 Hz
Standalone interactive display power consumption at	77°F (25°C)
Standby mode	≤0.5 W
Normal operating (out-of-box)	109 W
Operating temperature	41–95°F (5–35°C)
Storage temperature	-4–140°F (-20–60°C)
Humidity	5–80% relative humidity, non-condensing
Certification and compliance
U.S. / Canada	FCC, ISED, UL, CONEG Packaging, Cal Prop 65, Conflict Minerals, Energy Star
EU / EEA / EFTA	CE - LVD, RED, REACH, RoHS, Battery, WEEE, Packaging
EAEU	EAC
Australia / New Zealand	RCM
Taiwan	BSMI, NCC
Vietnam	ICT
South Africa	NRCS, ICASA
Warranty	Three years, advanced replacement

Tech Specs

Interactive Screens New Template
OS Support	Android
Resolution	4K UHD (3840x2160)
Screen Size	65 IN
Display Type	Interactive Flat Panel
Screen Type	LED LCD
Features	Built in Android, Built in Speakers
General Attributes
Warranty	3 YEARS
Product Weight	102 LBS
Shipping Weight	137 LBS
Product Height	36.63 IN
Product Length	3.75 IN
Product Width	59.69 IN
Shipping Height	45.75 IN
Shipping Length	10.75 IN
Shipping Width	66.38 IN

Brand	Smart
Model	MX265-V2
MPN	SBID-MX265-V2
