Product Description

The ABB OTPS40FPN2 is a fourth power pole designed for use with OT16-OT40F3 disconnect switches, intended for right side mounting. It is an auxiliary contact that provides a simultaneous function with the main contacts. This pole is suitable for DIN rail or panel mounting.

For use with OT16 to 40F3 DIN Rail and Base Mounted Switches
Simultaneous function with the main contacts
Suitable for use across OS, OT & OTDC ranges

Product Highlights

The ABB OTPS40FPN2 fourth power pole speeds up projects with a wide selection of accessories and adjustable shafts, increasing safety for applications.

Product Information

Standard Information

Brand: ABB
Manufacturer Part Number: OTPS40FPN2

Technical Specifications

Type: DISCONNECT
UNSPSC Code: 39121601
Accessory Type: Auxiliary Contact
Alternate Mfr Part Number: 1SCA105000R1001
Brand: ABB
Current Rating: 16 A
For Use With: OT16...40F3 DIN Rail or Panel Mounted
Manufacturer Part Number: OTPS40FPN2
Maximum Current: 1250 A
Mounting Type: DIN Rail Mount
Numeric ID: 4079255
Series: OT/OS/OTDC Series
Special Features: 4Th Pole Right side
Terminal Type: Lugs
UPC Code: 6417019391311
Voltage Rating: 600 VAC
Suitable For Use With: OT16 to 40F3 DIN Rail and Base Mounted Switches
Mounting type: Single
UNSPSC: 39122221
UPC: 06417019391311
Auxiliary Contacts (optional): Max. number allowed: 1-SPST per order, 300VDC @ 1A, 600VAC @ 10A; 2NO + 1NC
Wiring: EOT16 & EOT32: 8-18 AWG Terminals EOT45 & EOT63: 4-14 AWG Terminals Auxiliary: 14-18 AWG Terminals
Mounting: Tabs top and bottom, 4 knockouts
Enclosure Rating: NEMA 3R/12
Approvals: UL Listed E63822, IEC947-3, UL 508
Meets ARRA or BAA: Yes
Note: Only 1 additional pole per switch allowed

Brand	ABB
MPN	OTPS40FPN2

ABB OTPS40FPN2 Fourth Power Pole OT16-OT40F3 Disconnect Switch
