Product Description

The ABB TH3221R is designed for commercial and industrial applications where safety and high performance are essential. It is listed to UL standard 98 enclosed and dead front switches and certified to CSA standard 22.2 no. 4-04 enclosed and dead front switches. Meets or exceeds NEMA KS1 standard for enclosed switches, type HD.

Suitable for use as service equipment when installed in accordance with the National Electrical Code.
Fusible and non-fusible switches available.
Quick-make, quick-break mechanism.

Product Highlights

This heavy-duty safety switch is rugged, reliable, and easy to install. It features full cover interlocks and a 60/75 C conductor rating.

Product Information

Standard Information

Brand: ABB
Manufacturer Part Number: TH3221R

Technical Specifications

Enclosure: NEMA 3R (Outdoor)
Voltage Rating: 240 AC
Amperage Rating: 30A
Number of Poles: 2
Category: Heavy Duty
Wires: 3
Fusing: Fusible
Options: None
Wire Range (Cu/Al): 14-8 CU;12-8 AL
240 Vac, NEC Std, 1-ph: 1.5 hp
240 Vac, Time Delay, 1-ph: 3 hp
250 Vdc: 5 hp
GSA Compliance: Yes
cUL Listed: Yes
UL Listed: Yes
Mounting: Surface
Volts AC: 240
IP/NEMA Rating: NEMA 3R
Approval: UL 98, CSA
Neutral Type: No
Current Rating: 30 Amp
Fuse Provision: Fusible
DC Voltage Rating: 250 Volt
Fuse Type: Cartridge, Class H/J/R
AC Voltage Rating: 240 Volt
Enclosure NEMA Rating: NEMA 3R
Manufacturer: ABB
Component: Fusible Disconnect Switch
Current: 30 Amp
Poles: Two Pole
Enclosure Disconnect Type: Heavy Duty Safety Switch

Brand	ABB
MPN	TH3221R

ABB TH3221R 30A 240V AC Disconnect Switch
