STEPPERONLINE Nema 34 Closed Loop Stepper CNC Kit 1700oz.in Motor & CL86Y Driver
USD
$157.00
Seller:
stepperonline
100.0% positive
(13,906 reviews)
Perth Amboy, US
Out of Stock
US
Shipping
Standard Shipping
FREE
USPS Priority Mail
$30.00 USD
Request Quote
View on eBay
As an eBay Partner Network Affiliate, I earn from qualifying purchases.
Secure Transaction
Fast Response
Quality Guarantee
Specifications
| Brand | StepperOnline |
|---|---|
| Current Type | DC |
| Shaft Type | Keyway Shaft |
| Wiring Configuration | 4-Wire Bipolar |
| Shaft Diameter | Φ14mm |
| Full Step Angle | 1.8° (200 Steps) |
| MPN | 1-CLYS120-1M5-V20 |
| Actual Rated Input Voltage | 36-60VDC/30-70VAC |
| Holding Torque | 12.00Nm(1699.34oz.in) |
| Insulation Class | B 130°C[266°F] |
| Rated Current per Phase | 6A |
| Resistance per Phase | 0.59ohms ± 10% |
| Country of Origin | China |
| UPC | 742803058856 |
| EAN | 0742803058856 |
| Phase Resistance | 0.59ohms ± 10% |
| Rated Current/phase: | 6.0A |
| Inductance | 4.8mH ± 20%(1KHz) |
| Encoder Type | Optical Incremental |
| Output Circuit Type | Differential type |
| Encoder Resolution | 1000PPR(4000CPR) |
| Output Signal Channels | 2 channels |
| Keyway Shaft Length | 25mm |
| Cable Length | 1500mm |
| Isolation Resistance | 500MΩ |
| Pulse Width | 2.5μS |
| Driver Input Voltage | 20~80VAC/30~110VDC(Typical 48/60VDC) |
| Logic Input Current | 7~20mA |
