Product Description

The HONEYWELL ARD8TZ/U is an 8" Truezone 2-Wire Motorized Zone Damper. This automatic round damper features a power-close, spring-open design to ensure minimal leakage while controlling circulating air in heating, cooling, and ventilation systems. It is made of galvanized steel with a single-blade damper.

Features galvanized steel with single-blade damper, which closes off tightly against gasket for minimal leakage
Designated as power closed/spring return open damper for use with Honeywell zoning systems
Can be field-converted when used as an independent zone or for fresh air intake

Product Highlights

The Honeywell ARD8TZ/U damper is designed for use with Honeywell zoning systems and can be field-converted for independent zone or fresh air intake applications.

Product Information

Standard Information

Brand: HONEYWELL
Manufacturer Part Number: ARD8TZ/U
Country of Origin: US

Technical Specifications

Amperage Rating: 6 A
Country of Origin: MX
Domestic/Import: Import
Electrical Connections: M1-Power/M6-Common/M4 Terminal
Finish: Galvanized
Material: Steel
Motor Type: Power Closed, Spring Open
Rotation Angle: 90 deg
Series: ARD
Shape: Round
Size: 8 in
Temperature Rating: 40 to 140 deg F
Timing: 30 sec
Type: Single Blade
Voltage Rating: 24 VAC
Frequency: 60Hz
Damper Duct Shape Type: Round
Damper Type: Zone
Application: Zone Damper
Damper Material: Galvanized Steel
Activation: Electric
Actuator Housing Material: Molded Plastic
Actuator Power Consumption: 8 VA
Actuator Torque: 71 in-oz
Blade Material: Galvanized Steel
Leakage: Less than 1% at 0.5 in WC
Position Indicator Included: Yes
Position Indicator Type: Damper Position Range Stops, LED indication light for open and close
Range Stop: Yes
Range Stop Options: 4
Blade Type: Automatic, Power Closed, Round, Single, Spring Open
Height: 4-31/32 in
Motor Dimensions: 4-41/64 in L
Motor Specifications: 24 VAC, 60 Hz, 8 VA
Number of Blades: 1
Timing Range: 30 s
Torque Rating: 71 in-oz
VA Rating: 8 VA
Width: 3-61/64 in
Diameter (inches): 8
Approximate Weight (pounds): 3.80
Extended Length: 8.5 Inches

Brand	RESIDEO
MPN	ARD8TZ/U

RESIDEO ARD8TZ/U TrueZone 2-Wire Motorized Zone Damper 8" Round
