Product Description

The NSI GL25038 is a 250 MCM copper compression lug with a 3/8 bolt size. These compression connectors terminate high-current wires safely. It has a tin-plated copper body and a chamfered entry. These lugs are suitable for power distribution, grounding, and data transmission applications.

For Wire Size: 250 MCM
For Conductor Material: Copper
Material: Copper

Product Highlights

The NSI GL25038 copper compression lug ensures a secure and reliable connection for high-current wiring needs.

Product Information

Standard Information

Brand: NSI
Manufacturer Part Number: GL25038
Country of Origin: India

Technical Specifications

MFR #: GL25038
For Wire Size: 250 MCM
Barrel Size: Short
Width: 1.091"
Length: 2.48"
Cable Size: 250 MCM
Barrel Length: 1
Barrel Outside Diameter: 0.75
Barrel Inside Diameter: 0.59
Mounting Bolt Size: 3/8
Tang Length: 1.06
Tang Thickness: 0.15
Item: One-Hole Compression Lug
For Conductor Material: Copper
Material: Copper
Color Code: Yellow
Standards: UL 486A-486B, cULus
Connector Type: Short Barrel with Peep Hole
Color: Yellow
Environmental Conditions: 90 C
Type: Short Barrel - One Hole
Voltage Rating: 600 V
Application: Terminate
Number of Holes: 1
Mounting: 3/8 Mounting Hole
Finish: Tin Plated
Conductor Type: Copper
Ul File No: E155027
Wire Cable Class: Class B, Class C
Certifications: cULus
Assortment: Copper Compression Terminations
Expanded Wire Range: 250 MCM "> – 1/0 AWG
Temp Rating: 90C, 9CU
Ul Standard: UL 486A-486B, UL 467 (8 AWG "> – 3/0 AWG)
Brand: NSI Industries
Part Number: GL25038
GTIN: 662381036438
UPC: 662381036438
EAN: 662381036438
UNSPSC: 39121405
Origin Country: IN
Stud Size: 3/8
Die Color Code: Yellow
I.D.: 0.59
O.D.: 0.75
Wire Range: 250 MCM
Operating temperature: 90 C
Product Type: Copper Short Lug
Manufacturer: NSI
Al Conductor Max Amp: 230
Cu Conductor Max Amp: 290
Conductor Cu Size Range: 250 MCM-6 AWG
Conductor Al Size Range: 250 MCM-6 AWG
Env Temp: 90C, 9CU
Max Torque: 360

Brand	NSI INDUSTRIES
MPN	GL25038

NSI GL25038 250 MCM Copper Compression Lug 3/8 Bolt
