Product Description

The ABB CTL40-38 is a non-insulated, one-hole copper compression terminal designed for reliable electrical wiring. This short barrel lug accommodates 4/0 AWG stranded, flexible, welding, and portable copper conductors, suitable for industrial and building applications up to 35 kV. It features a 3/8 inch stud size and is tin plated for corrosion resistance, ensuring durability in various environments.

For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for industrial and building applications.
Color-coded for matching die identification.
Specifically chamfered barrel for ease of installation.

Product Highlights

High-conductivity seamless copper tubing, tin plated for corrosion resistance, and color-coded for easy die identification.

Product Information

Standard Information

Brand: ABB
Manufacturer Part Number: CTL40-38
Country of Origin: Mexico

Technical Specifications

Brand Name: ABB
Sub Brand: BlackburnÂ®
Manufacturer: ABB Installation Products
Item Name: Compression Lug
Product Type: Terminals
Category: Cable or wire lug
Series: CTL
Type: Non-Insulated
Material: Copper
Conductor Size: 4/0 AWG Stranded
Conductor Type: Flexible/Stranded Copper
Stud Size: 3/8 in
Number of Holes: 1
Number of Studs: 1
Voltage Rating: 35 kV
Finish: Tin Plated
Color: Purple
Die Color: Purple
Barrel Type: Short, Straight
Barrel Shape: Standard
Barrel Length: 15/16 in
Tongue Type: Straight
Tongue Angle: Straight
Tongue Size: 29/32 in L x 1-3/32 in W x 1/8 in THK
Terminal Connection: Ring
Insulated: No
Sight-Hole: No
Connecting Angle: 180Â° (horizontal)
Slender Flange Model: No
Certifications: UL, CSA
Standards: UL E9809
UL File Number: E9809
CSA File Number: 6591
CSA Class: 622302
RoHS Compliance: RoHS3 Compliant
REACH Compliance: REACH 247 Compliant
TSCA Compliance: TSCA Section 6(h) Compliant
ETIM Classification: EC001051 Tube cable lug for copper conductors

Brand	ABB
MPN	CTL40-38

ABB CTL40-38 Compression Terminal 4/0 AWG 3/8 Bolt 1-Hole
