Product Description

The EATON M22-KC10 is a non-illuminated contact block from the M22 series. This 22.5 mm block features a 1NO contact configuration and is suitable for automation and logic control equipment applications. It has a screw terminal and is designed for surface mounting.

Ergonomic design ensuring ease of operation and bright illumination
Vibration resistant LEDs giving a minimum life of 100000 hr for improved reliability and high integrity
Fitting in the standard 22.5 mm hole, the snap fitting modular system saves both assembly and fitting time

Product Highlights

Eaton's M22 contact block offers reliable connectivity with its positively driven NC contacts and vibration-resistant LEDs.

Product Information

Standard Information

Brand: EATON
Manufacturer Part Number: M22-KC10
Country of Origin: Germany

Technical Specifications

Application: Automation and Logic Control Equipment Applications
Contact Configuration: 1NO
Contact Rating: 4 A at 230 VAC, 2 A at 500 VAC
Enclosure: IP66
Manufacturer Part Number: M22-KC10
Mounting Type: Surface
NEMA Rating: NEMA 4X/13
Series: M22
Size: 22.5 mm
Standards/Approvals: UL 489|CCC Marked|CE Marked|CSA 22.2|HACR Rated|Lloyd's Register Certified|GoST-R Certified|Bureau Veritas Certified
Terminal Type: Screw
Type: Non-Illuminated
Product Length/Depth: 1.46 in
Product Width: 1.18 in
Compliances: CE Marked Bureau Veritas GoST-R
Certifications: CCC Marked CSA Certified Lloyd's Register Certified
Catalog Notes: All NC contact blocks are positively driven contact
Product Type: Pushbutton accessory
Special features: NC contact blocks are positively driven
Actuator: Base, screw
Environmental rating: IP66, NEMA 4X, NEMA 13
Brand: EATON
Compatible with Series: M22; M22M
Compatible Operator: Push Button
AC Contact Rating: 2 A @ 500 V; 4 A @ 400 V; 6 A @ 115 V; 6 A @ 230 V
Contact Form: 1NO
NEMA Contact Rating Designation: A600/Q300
Panel Mounting Hole Diameter: 22 mm
Standards: Bureau Veritas; CCC; CE; CSA; GOST-R; Lloyd's Register
Switch Action: Momentary
Terminal Connection Type: Spring Cage
Terminals: UNSPSC 39121512

Brand	EATON
MPN	M22-KC10

EATON M22-KC10 Contact Block 1NO 22.5mm Screw Terminal
