Product Description

Marathon Special Products 1512SC is a 1500 Series 12-position power distribution terminal block for screw-clamp connections in industrial control and power distribution applications. The block features a phenolic base rated to 150 C, brass nickel-plated connectors and Phil-slot 10-32 screws, plus a short circuiting bar with brass insert and four shorting pins. Line-to-line spacing is 0.625 in (15.88 mm). Rated 30 A with unprepared #10â22 AWG copper and up to 75 A with crimp terminals at 600 V.

12-position 1500 Series terminal block with screw-clamp connections and surface-mount design
Electrical rating: 30 A with unprepared #10â22 AWG copper; up to 75 A with crimp-type ring, spade, or fork terminals; 600 V
Materials and mechanicals: phenolic base (150 C UL RTI), brass nickel-plated connectors, Phil-slot 10-32 screws, 0.625 in (15.88 mm) spacing, shorting bar with four shorting pins

Product Highlights

12-position power distribution block, 30 A/600 V rating, phenolic base with brass nickel-plated connectors and included shorting bar

Product Information

Standard Information

Brand: MARATHON SPECIAL PRODUCTS
Manufacturer Part Number: 1512SC

Technical Specifications

Brand: Marathon Special Products
Manufacturer Part Number: 1512SC
Series: 1500 Series
Number of Poles: 12
Connection Type: Screw clamp (Phil-slot, 10-32 screws)
Mounting Type: Surface mount
Wire Size Range: 10-22 AWG
Rated Current: 30 A with unprepared wire; up to 75 A with crimp-type ring/spade/fork terminals
Rated Voltage: 600 V
Base Material: Phenolic
Base Temperature Rating: 150 C (UL RTI)
Connector Material: Brass, nickel plated
Shorting Bar: Included; brass insert with four shorting pins
Line-to-Line Spacing: 0.625 in (15.88 mm)
Dimensions (H x W x D): 2.00" x 1.19" x 8.25" (inches)
Hole Size: 0.22"
Approvals: CE, CSA, UR
Net Weight: 0.975 lb
Primary Use / Category: Terminal Blocks & Strips

Brand	MARATHON SPECIAL PRODUCTS
MPN	1512SC

Marathon Special Products 1512SC Terminal Block 12-Position 30A 600V
