Overview

SMC ANA1-02 is a high noise reduction pneumatic silencer engineered for industrial compressed air systems. The ANA1 silencer keeps the noise level inside a plant below 85dB(A) with a noise reduction effect of 40dB(A). With a 1/4 BSPT port size and overall length of 64 mm, this compact muffler provides effective exhaust silencing in space-constrained installations. The screw-in design enables quick, tool-free replacement on existing pneumatic circuits.

Key Features

High Noise Reduction: Provides significant noise reduction of up to 40 dB(A), bringing plant noise to industrial-acceptable levels
Compact Form Factor: 64 mm overall length with 18 mm hex size allows installation in tight spaces
Screw-in Connection: Direct threaded fitting eliminates the need for adapters or special tools
Wide Operating Range: Operating temperature range from +5 to +60 Â°C and maximum operating pressure of 1 MPa
Industrial Standard Material: Designed to meet JIS standards with durability for demanding pneumatic environments
Lightweight: Weight of 0.04 lbs enables flexible mounting configurations

Technical Specifications

Model: ANA1-02
Noise Reduction: 40 dB(A)
Port Size: 1/4 inch (R 1/4 BSPT / NPT threaded)
Operating Medium: Compressed air
Operating Pressure: Maximum 1 MPa (10 bar / 145 psi)
Operating Temperature: +5 to +60 Â°C (+41 to +140 Â°F)
Overall Length: 64 mm
Hex Size: 18 mm
Weight: 0.04 lbs per unit
Standards: JIS compliant
Country of Origin: Japan

Typical Applications

The silencer effectively dampens exhaust noise from pneumatic equipment, making it ideal for applications where noise control is critical. The ANA1 series is engineered for durability and efficient operation in various industrial environments, offering a balance of noise suppression and minimal impact on system performance.

Common uses include:

Industrial pneumatic cylinder exhaust ports
Solenoid valve discharge silencing
Air tool compressor outlet noise reduction
Manifold common exhaust silencing
Manufacturing plants requiring OSHA-compliant noise levels

Compatibility & Replacements

Compatible With

SMC pneumatic components with 1/4 inch NPT/BSPT threaded ports
Industrial pneumatic systems operating at 1 MPa maximum pressure
Compressed air lines requiring aftermarket silencing
Solenoid valve exhaust ports on pneumatic circuits

Replaces / Drop-In Replacement For

The SMC ANA1-02 is a direct replacement for existing 1/4 NPT/BSPT high-reduction silencers. Verify the port thread type (R 1/4 BSPT vs. NPT) on your existing component before ordering to ensure compatibility. Consult your system integrator or pneumatic component documentation if uncertain of the port standard.

Works With

SMC ANA1 series silencer lineup
Pneumatic cylinders and actuators
Air solenoid valves and manifolds
Compressed air distribution systems
Industrial plant noise control systems

Powered by SixBit's eCommerce Solution

Brand	SMC
Thread Standard	NPT
Model	ANA1-02
MPN	ANA1-02
Country of Origin	Japan

SMC ANA1-02 Pneumatic Silencer Muffler 1/4 NPT High Reduction Type Pack of 10
