12v 5amp Multi Function timer. On and Off delays. 25 functions. Water resistant

Multifunctional Timer delay module is a revolutionary circuit with many commonly used timer delay and signal processing functions. It is perfect for many applications from hobby to industrial controls. The timer has more than thirty different timing functions with the optional ability to trigger by application of voltage to the trigger wire. Dry contacts can be used as a trigger as well. The timer can be used for hundreds of various applications from delaying power to the circuit, supplying power in cycling fashion, or creating a self-latching timed circuit. The timer is easy to connect and configure. All the configurations are permanently saved into the internal flash memory. The timer works with 6V to 28V supply voltage and can handle up to 10 amp of current. Wide voltage supply range and high current capabilities make the timer applicable to the variety of applications. The maximum current can be extended with the use of the external relay. The timer can run in Low Power mode which is suitable for battery-powered applications.

The timer’s configuration changes are done via a smartphone or computer connected to the timer via a Wi-Fi network. Timer’s firmware is upgradable allowing the user to flash updates and extend the functionality of the device.

Some examples of the timer applications:

Delay power to the device like an amplifier for a couple of seconds.
Supply output power for the precise amount of time after power is applied.
Keep the vehicle fan or GPS running for a period of time after the ignition is turned off.
Turn the sump pump for 30 sec every 10 min.

Minimum time duration - 0.1 sec

Maximum time duration - 400 days

Timer functions - 33+ configurable via smart phone

Output: Positive or Ground Sink

Trigger - high or low (optional)

Firmware update

Input voltage - 6V - 28V

Current consumption - 1.5ma (0.05ma in Low Power mode)

Brand	Timers.shop
MPN	TIMER10

6V-28V 10 Amp Timer Wi-Fi (configurable via phone)
