New factory sealed TURCK ERKBG-A4.400.2-2 Actuator and Sensor Receptacle – Front Mount 100012206.

Free Ground shipping

The TURCK ERKBG-A4.400.2-2 is a rear-mount actuator and sensor receptacle designed for industrial applications. It features a 4-pin M12 × 1 A-coded female connector, compliant with IEC 61076-2-101 standards, ensuring reliable connectivity for sensors and actuators. The receptacle is equipped with a 2-meter (approximately 6.5 feet) cable terminated with bare-end flying leads, facilitating integration into various control systems. Its nickel-plated brass housing provides durability and resistance to environmental factors.

Features:

Connector Type: 4-pin M12 × 1 A-coded female connector
Mounting Style: Rear mount with PG9 mounting thread
Cable Length: 2 meters (approximately 6.5 feet)
Cable Termination: Bare-end flying leads
Housing Material: Nickel-plated brass
Contact Material: Gold-plated bronze (CuSn)
Contact Carrier Material: Black TPU (thermoplastic polyurethane)
Sealing: O-ring made of FKM/FPM for secure sealing

Applications:

Industrial automation systems
Sensor and actuator connectivity
Control panels
Machine building

Specifications:

Rated Voltage: 250 VAC / 300 VDC
Rated Current: 4 A
Conductor Size: 22 AWG (approximately 0.34 mm²)
Conductor Material: Tinned copper (TC)
Conductor Insulation Material: PVC
Conductor Colors: Brown (BN), White (WH), Blue (BU), Black (BK)
Protection Class (When Coupled): IP67, IP68, IP69, IP69K; NEMA: 1, 3, 4, 6P, 12
Mechanical Life: >100 mating cycles
Ambient Temperature Range (Static): -40 °C to +105 °C
Approvals: UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS

Please note:

This is not an exhaustive list of features, applications, and specifications. For more detailed information, compatibility details, and to verify any claims listed, please refer to the manufacturer's documentation.

Brand	Turck
Model	EFKBG-A4 .400.2
MPN	100012206
