Product Description

The FRAME 688117 is a replacement frame component designed for use in dishwasher applications. Frame parts serve a structural or mounting role within the appliance, securing panels, door assemblies, or interior components in their proper position. This part is sourced from the Bosch parts and accessories line, making it relevant to technicians and service professionals performing repairs on Bosch dishwasher units. Installation typically requires basic hand tools and familiarity with appliance disassembly procedures.

This frame component is suited for residential dishwasher service and repair scenarios where the original frame has become damaged, warped, or otherwise non-functional. It is classified under Bosch Home Appliance Parts and Accessories, specifically within the Bosch Dishwasher Parts category. Service technicians should reference the unit's model and serial number to confirm fitment before ordering.

Key Features

OEM-style replacement frame component for dishwasher applications
Designed to restore structural integrity to the dishwasher assembly
Part of the Bosch Home Appliance parts and accessories catalog
Direct replacement intended to match original factory dimensions and mounting points

Compatibility

Designed as an OEM-style replacement frame for Bosch dishwasher models. Verify compatibility using the appliance model and serial number before installation.

Installation Notes

Appliance technicians should disconnect power to the dishwasher at the circuit breaker and shut off the water supply before beginning any disassembly. Frame replacement typically involves removing door panels or interior components to access mounting hardware. Standard hand tools such as screwdrivers and nut drivers are generally sufficient for this type of repair. Follow all applicable local appliance service codes and manufacturer service documentation.

Technical Specifications

Part Type: Frame
Application: Dishwasher

Standard Information

Brand: FRAME
Manufacturer Part Number: 688117

Brand	BOSCH
MPN	00688117

BOSCH 00688117 Dishwasher Frame Part
