Product Description

Marathon Special Products 1504STD is a 4-pole terminal block in the 1500 series designed for heavy-duty electrical connections. It is rated 30 A/600 V for bare wire and up to 75 A with prepared or crimped wire, accepts 22â10 AWG conductors, and uses screw-clamp connections with top wire entry. The unit mounts to a surface, has a 15.9 mm center spacing, and carries CE, CSA and UR approvals.

Rated 30 A/600 V for bare wire, up to 75 A with prepared/crimped wire; accepts 22â10 AWG.
Screw-clamp connection type with top wire entry and surface-mount installation; 15.9 mm center spacing.
Heavy-duty 4-pole construction with CE, CSA, and UR approvals; H x W x D: 2.00 x 1.19 x 3.25 in.

Product Highlights

4-pole heavy-duty screw-clamp terminal block, 30 A/600 V (75 A with crimp), accepts 22â10 AWG.

Product Information

Standard Information

Brand: MARATHON SPECIAL PRODUCTS
Manufacturer Part Number: 1504STD
Country of Origin: United States

Technical Specifications

Manufacturer: Marathon Special Products
Manufacturer Part Number: 1504STD
Product Series: 1500
Family Series: Marathon Special Products Terminal Blocks, 1500 Series
Number of Poles: 4
Connection Type: Screw clamp
Rated Voltage: 600 VAC
Wire Size Range: 22-10 AWG
Current Rating: 30 A (bare wire); 75 A (with prepared/crimped wire)
Mounting Type: Surface mount
Wire Entry Position: Top
Center Spacing: 15.9 mm
Dimensions: 2.00 x 1.19 x 3.25 in (H x W x D)
Net Weight: 0.3045 lbs
Hole Size: 0.2 in
Raised Mounting: No
Pluggable: No
Approvals: CE, CSA, UR
Certifications/Ratings: UL, CSA, IEC rated to 600 VAC
Color: Black
Country of Origin: United States

Brand	MARATHON SPECIAL PRODUCTS
MPN	1504STD

Marathon 1504STD Terminal Block 30A 600V 4-Pole 22-10AWG
