Product Description

The ABB AF49SD is a replacement filter front panel designed for surface-mount filter applications measuring 49.5 x 20 inches. This component serves as the front-facing retention or cover panel for a filter assembly, providing a secure interface between the filter media and the enclosure or housing it protects. It is commonly installed by HVAC technicians, electricians, or panel fabricators working on electrical enclosures or air-handling equipment that require accessible filter fronts. At 23 pounds, it is a substantial panel suited for commercial or industrial installations where durable filter housing components are required.

The AF49SD is applicable in surface-mount configurations where a 49.5 x 20 inch filter front is specified. This type of component is typically found in electrical enclosures, control panels, or ventilated equipment cabinets that use filtered air intake to protect internal components. Installation is performed during enclosure assembly or as part of a service replacement when an existing filter front is damaged or worn.

Key Features

Surface-mount design for direct panel installation without recessed framing
49.5 x 20 inch filter front footprint suited for large enclosure or cabinet openings
Substantial 23-pound construction indicating heavy-duty panel material
Replacement-style component for straightforward like-for-like serviceability

Compatibility

Designed as an OEM-style replacement filter front for surface-mount filter assemblies requiring a 49.5 x 20 inch panel configuration.

Installation Notes

Installation is typically performed by licensed electricians or qualified panel technicians. De-energize all associated equipment and follow applicable NFPA 70 (NEC) lockout/tagout procedures before servicing the enclosure or cabinet. Ensure the mounting surface is clean and free of obstructions before securing the filter front. Do not force-fit the panel if the opening dimensions do not match the specified 49.5 x 20 inch footprint.

Technical Specifications

Filter Front Dimensions: 49.5 x 20 inches
Package Dimensions (L x W x H): 4.750 x 2.080 x 1.000 inches
Weight: 23 pounds
Mount Type: Surface mount
UPC: 78317505289

Standard Information

Brand: ABB
Manufacturer Part Number: AF49SD

Brand	ABB
MPN	AF49SD

ABB AF49SD Replacement Filter Front 49.5 X 20
