Product Description

The ABB Installation Products CF22-1 is a Figure H shaped compression overhead cable tap, designed for reliable cable-to-cable connections. Constructed from extruded electrolytic pure copper, this connector ensures high conductivity for copper conductors. It accommodates run and tap conductors from 4 AWG stranded/solid up to 2 AWG solid, utilizing die indices K, W-KK, or BKT for proper installation. This RUS approved connector is part of the CF series.

Made of Pure Electrolytic Copper to Provide High Conductivity
Efficient Design Requires Less Crimping Force
Full Length Tab Makes Installation Easy

Product Highlights

Installs with standard compression tools and dies for reliable cable connections.

Product Information

Standard Information

Brand: ABB INSTALLATION PRODUCTS
Manufacturer Part Number: CF22-1
Country of Origin: Mexico

Technical Specifications

Connector Type: Compression Overhead Cable Tap
Shape: Figure H
Conductor Type: Copper
Die Index: K, W-KK, BKT
Manufacturer Series: CF
Number of Taps: 2
Minimum Run Conductor Size: 4 AWG Stranded (Standard), 4 AWG Solid (Copper, Standard)
Maximum Run Conductor Size: 4 AWG Stranded, 2 AWG Solid (Copper)
Minimum Tap Conductor Size: 4 AWG Stranded (Standard), 4 AWG Solid(Copper, Standard)
Maximum Tap Conductor Size: 4 AWG Stranded (Standard), 2 AWG Solid (Copper, Standard)
Body Material: Extruded Electrolytic Pure Copper
Approval: RUS

Brand	ABB INSTALLATION PRODUCTS
MPN	CF22-1

ABB CF22-1 Compression Overhead Cable Tap Copper Figure H
